Native 4K 4,096 x 2,160 pixels
Refined Sleeak Design, Native 4K, BLU-Escent Laser Discover Your Next Cinematic Journey
- D-ILA Technology: Yes
- Chip Type: 0.69-inch 4K D-ILA device
- Native Resolution: 4096 x 2160
- Number Of Chips: 3
- Display Resolution: 4096 x 2160
Light Source
- Laser: Yes
- Type: BLU-Escent Laser Diode
- Life Time (Standard Mode): 20000 hours
- Brightness: 2000 lm
- Dynamic Contrast: ∞ : 1
- Native Contrast: 40000 : 1
- Dynamic Light Power control: Yes
- Modes: Low,High,Balance,Off
- Manual Aperture: Yes
- Range: -15 (stops down) to 0 (opens up)
- 100% REC 709: Yes
- Color Bit Depth: 12 bit
- ISFccc Certification: Yes
HDR
- HDR10: Yes
- HDR10+: Yes
- Frame Adapt HDR: Yes
- HLG: Yes
- Mastering Info Display: Yes
- Info data: MaxCLL, MaxFALL , DML
- Deep Black Tone Control: Yes
Lens
- Zoom: 1.6 x
- Throw Ratio: 1.34 - 2.14 (16:9); 1.26 - 2.01 (17.9)
- Diameter: 80 mm
- Build: 15-element, 11-group.
- Lens Shift: Yes
- Range Horizontal: ± 28 %
- Range Vertical: ± 70 %
- Motorized Zoom: Yes
- Motorized Shift: Yes
- Motorized Focus: Yes
- Projection Display size (diagonal): 60 - 200 inch
- Memory Function: Yes
- Number of user presets: 5
- Lens Cover: Yes
HDMI
- HDMI: Yes
- Number of Inputs: 2
- Data Rate: 32 Gbps
- HDCP Version: 2.3
- 4K60P signal input: Yes
- Video Signal range: 480p, 576p, 720p 60/50, 1080p 60/ 50/ 30/ 25/ 24, 3840 x 2160p 60/ 50/ 30/ 25/ 24, 4096 x 2160p 60/ 50/ 30/ 25/ 24
- PC Signal range: 640x480, 800x600, 2048x1080, 1600x1200, 1920x1200, 2048x1536, 2560x1440
- Input Level Adjustment: Auto / Standard (16-235) / Enhanced (0-255) / Super White (16-255)
- Color Space Range: Auto/ YCbCr444 / YCbCr422 / RGB
- EDID Modes: Standard, Option1 , Option2 (older hardware may need to use Option1 or Option2 settings)
Connections
- LAN: Yes
- Connector: RJ45
- Service: Yes
- Connector: USB (Type A) for firmware update or backup
Picture Settings
- Picture Modes: Natural, Cinema, Filmmaker, Vivid, Frame Adapt HDR1,Frame Adapt HDR2, HDR10+, HLG, FilmMaker, 4 User modes
- Color Temperatures: 5500K, 6500K, 7500K, 9300K, High Bright, HDR10+, HDR10, HLG, Custom 1, Custom 2
- Gamma Processing Depth: 12 bit
- Gamma Adjust: HDR (Auto), HDR(PQ), HDR(HLG), 2.2, 2.4, 2.6, Cinema 1, Cinema 2, Vivid, 3 Custom modes
- Color Management: 6-Axis adjustable CMS
- MPC: Yes
- Filmmaker Mode: Yes
- Low Latency Mode: Yes
- Auto Calibration: Yes
- Installation Mode: Yes
- Number of modes: 5
- Included settings: Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, and Aspect
- Anamorphic Modes: 4 Modes (A, B, C, D)
- Control4 SDDP: Yes
Power & Environment
- Power Requirement: AC100-240V, 50/60Hz
- Projector in Use: 280W
- Standby: Eco-mode: 0.3W
- Network Standby: 1.5W (LAN)
- Eco Mode: Yes
- Standby Timer: Yes
- Operating Temperature: 5°C to 35°C
- Operating Humidity: 20% to 80%
- Installation Angle: Horizontal +/- 10 degree / Vertical +/- 10 degree
- Installation Height: Below 2,000 m
In the box
- Remote Control: Yes, RM-MH27
- Quick Guide: Yes
- Power Cord: Yes
- Batteries: Yes, 2 x AAA-size batteries
Dimensions & Weight
- Product Dimensions (WxHxD): 450 x 181 x 479 (mm)
- Product Weight: 14.6 Kg
- Package Dimensions (WxHxD): 585 x 361 x 600 (mm)
- Package Weight: 18.9 Kg
General Editing Note
- General Note:
- Simulated pictures.The values for weight and dimensions are approximate.E.&O.E. Design and specifications subject to change without notice.
